Double-walled casings can be used universally, as they are designed for transmitting high rotational and vertical forces as created by the rotary drives and oscillators.
The use of double-walled casings ensure a flush drill string.
The casing are made of double-wall pipes. Casing connections on both sides with female and/or male part and conical and/or threaded rings with O-ring. Betek screw connections.
Technical Dimensions
| D1/D2 (mm) | 1m (kg) | 2m (kg) | 3m (kg) | 4m (kg) | 5m (kg) | 6m (kg) | C1 (mm) | C2 (mm) | E (mm) | Bolt (Num.) |
|---|---|---|---|---|---|---|---|---|---|---|
| 620/540 | 403 | 739 | 1074 | 1411 | 1747 | 2081 | 12 | 8 | 40 | 8 |
| 750/670 | 492 | 902 | 1311 | 1722 | 2131 | 2540 | 12 | 8 | 40 | 10 |
| 880/800 | 585 | 1069 | 1552 | 2036 | 2520 | 3005 | 12 | 8 | 40 | 10 |
| 1000/920 | 669 | 1221 | 1773 | 2326 | 2877 | 3429 | 12 | 8 | 40 | 10 |
| 1180/1100 | 844 | 1580 | 2316 | 3052 | 3787 | 4522 | 16 | 8 | 40 | 12 |
| 1200/1120 | 872 | 1620 | 2370 | 3120 | 3870 | 4620 | 16 | 8 | 40 | 12 |
| 1300/1220 | 933 | 1746 | 2558 | 3372 | 4184 | 4995 | 16 | 8 | 40 | 12 |
| 1500/1400 | 1433 | 2625 | 3817 | 5009 | 6201 | 7393 | 20 | 10 | 50 | 12 |
| 1800/1700 | 1730 | 3166 | 4602 | 6038 | 7474 | 8910 | 20 | 10 | 50 | 16 |
| 2000/1880 | 2450 | 4280 | 6110 | 7940 | 9770 | 11600 | 20 | 15 | 60 | 12 |
| 2200/2080 | 2700 | 4720 | 6740 | 8760 | 10780 | 12800 | 20 | 15 | 60 | 12 |
| 2500/2380 | 2960 | 5240 | 7520 | 9800 | 12080 | 14360 | 20 | 15 | 60 | 16 |
