Casing systems with screw joints are available with single or double wall. The double wall is designed specifically for high torque drilling rigs. Casing Shoes can be fitted with tooth holders or weld-in wearparts, optional solid wall construction & wear protection in the form of vertical wearplate available.
Technical Data
| Diameter | 600 mm |
|---|---|
| Weight | 250 kg |
| Connection | Square drive |
Technical Dimensions
| Casing Ø (mm) | Joint (mm) | Wall Thickness (mm) | Length (m) |
|---|---|---|---|
| 880/800 | 40 | 12+8 | 1, 2, 3, 4, 5 |
| 1000/920 | 40 | 12+8 | 1, 2, 3, 4, 5 |
| 1180/1100 | 40 | 15+8 | 1, 2, 3, 4, 5 |
| 1300/1220 | 40 | 15+8 | 1, 2, 3, 4, 5 |
| 1650/1550 | 50 | 20+15 | 1, 2, 3, 4, 5 |
| 1800/1700 | 50 | 20+15 | 1, 2, 3, 4, 5 |
